Item

Parameter

Item

Parameter

Cutter Qty.

N

8；12

Repeat Accuracy

mm

<0.005

Center Height

63/80/100/125/160

Indexing Accuracy

mm

-7''~+7''

Max rotary inertia

Kgm²

1.8

Work Pressure

MPa

3.5

转45º时间

Time of rotate to 45º

S

0.25/0.25/0.25/0.3/0.6

工作流量

Work flow rate

L/min

18/20/22/25/30

Time of rotate to 45º and tighten

S

0.5/0.5/0.6/0.6/1

Max un-balance force moment

Nm

15/20/30/50/100

Time of rotate to 180º

S

1.0

Max tangent moment

KNm

1.2/1.5/2.5/3.6/5

Time of rotate to 180º and tighten

S

1.3/1.3/1.4/1.5/3

Net weight

(without cutter-head)

Kg

48/60/85/135/190
